Muvix R
Rugged outdoor rental LED platform with 3.9mm pixel pitch and IP65 protection. Designed for concerts, festivals, and touring event systems with ultra-bright 4500-5000 cd/m² performance.
- 🌊Ultra-bright 4500-5000 cd/m² outdoor visibility
- 🛡️IP65 protection front & rear weatherproofing
- 🎨3.9mm pixel pitch for outdoor clarity
- ⚡≥3,840Hz refresh rate performance
- 🔧Front/rear servicing for easy maintenance
- 🎭Portable touring-friendly design
Outdoor Performance
Ultra Bright & Weather Resistant
Muvix R extends the Muvix rental philosophy into outdoor environments. It is designed for temporary event use where teams need fast assembly, repeatable operation, and polished presentation in open-air venues. With ultra-bright 4500-5000 cd/m² performance and IP65 protection, it delivers exceptional visibility in direct sunlight.
Ideal Applications
- •Concerts
- •Festivals
- •Temporary outdoor stages
- •Touring setups
- •Brand activations
4500-5000 cd/m² ultra-bright outdoor performance
IP65 weatherproof protection front & rear
Outdoor rental LED platform technology
Portable touring-friendly positioning
Event Ready
Modular Setup & Maintenance
Built for repeated deployment with fast assembly and teardown capabilities. The modular event-focused structure ensures quick setup for temporary outdoor stages, brand activations, and touring setups with front/rear servicing access.
Key Features
- •Modular event-focused structure
- •Built for repeated deployment
- •Suitable for outdoor staging
Fast assembly and teardown for events
Front/rear servicing for easy maintenance
Fast setup and removal capabilities
Portability and speed optimization
Visual Excellence
High Performance Visuals
Delivers outstanding outdoor visual performance with 3.9mm pixel pitch clarity, ≥3,840Hz refresh rate, and 14-16 bit grayscale processing. Perfect for high-profile outdoor installations where every detail matters in bright ambient conditions.
Technical Snapshot
3.9mm pixel pitch for outdoor clarity
≥3,840Hz refresh rate for smooth motion
14-16 bit grayscale processing
160° viewing angle coverage
Technical Datasheet
Display Specifications
| Pixel Pitch | 3.9 mm |
| LED Type | SMD 3-in-1 1921 mm |
| Pixel Density (m²) | 65,536 dot/m² |
| Resolution (Module) | 64×64 pixels |
| Resolution (Cabinet) | 128×128 / 128×256 pixels |
| Module Size | 250×250 mm |
| Modules Per Cabinet | 2×2 / 2×4 |
Physical & Construction
| Cabinet Size | 500×500×93mm / 500×1000×93mm |
| Cabinet Area | 0.25 m² / 0.5 m² |
| Weight | ≤8.5 kg / ≤13 kg |
| Material | Die-cast Aluminum/Magnesium |
| Aspect Ratio | 16:9 |
| Flatness | ≤0.3 mm |
| Servicing | Front/Rear |
Optical Parameters
| Brightness | 4500-5000 cd/m² |
| Contrast Ratio | 5,000:1 |
| Viewing Angle (H) | 160° |
| Viewing Angle (V) | 160° |
| Color Temperature | 2000-10000K Adjustable |
Electrical & Environmental
| Power (Max) | ≤680 W/m² |
| Power (Avg) | ≤220 W/m² |
| Input Voltage | AC 100-240V, 50/60Hz |
| Refresh Rate | ≥3840 Hz |
| Frame Rate | 30-60 Hz |
| Operating Temp | -20 – 50°C |
| IP Rating | IP65 (Front & Rear) |
| Lifespan | 100,000 Hrs |
Outdoor Applications
Concerts & Festivals
Main stage displays and side screens
Outdoor Events
Corporate launches and brand activations
Touring Systems
Portable rental configurations
