Prismix Elite
Higher-spec flip-chip COB display platform featuring proprietary Munorix INX Driver IC and revolutionary all-in-one chip technology. Delivers zero delay processing with 7680Hz ultra-high refresh rate.
- 🔌Munorix INX Driver IC all-in-one chip
- ⚡Zero delay processing (109ms response)
- 📊7680Hz ultra-high refresh rate
- 🌈22-bit native grayscale depth
- 🔋35% lower power consumption
- 🎬HDR support with superior brightness
Revolutionary Technology
Ultra Thin And Light
At the heart of Prismix Elite is our proprietary Munorix INX Driver IC- a revolutionary all-in-one chip that integrates row drivers, column drivers, logic processing, and a receiving card. This innovation simplifies LED architecture, reduces the number of components, and enhances overall display performance.
All-in-One Integration
Row drivers, column drivers, logic processing in single chip
Simplified Architecture
Reduces component count and enhances performance
Enhanced Reliability
Fewer components mean higher system reliability
Performance Excellence
Wireless ClickShare
Prismix Elite delivers power-packed performance with zero delay processing, ensuring real-time smooth content delivery. With 35% reduced power consumption and 7680Hz ultra-high refresh rate, it's ideal for applications where timing is critical.
Zero Delay Processing
Real-time smooth content delivery with zero frame delay
Common Cathode Technology
35% power consumption reduction for sustainable operation
7680Hz Ultra High Refresh Rate
Flicker-free, lag-free visuals for broadcasting and retail
Mission-Critical Applications
Perfect for control rooms and executive spaces
Flagship Premium Positioning
Elite fine-pitch applications and luxury boardrooms
Visual Excellence
Stunning Visuals
Prismix Elite- the next gen of Prismix, is engineered to deliver cinematic-quality visuals outperforming traditional LED displays in every way. Features 22-bit native grayscale depth and HDR support for unrivalled visual brilliance.
📋 Prismix Elite Technical Datasheet
Display Specifications
| Product Series | Prismix-Ultra |
| Pixel Pitch (mm) | 0.625 | 0.78 | 0.9375 | 1.25 |
| Packaging Process | Full flip-chip COB |
| Pixel Density (dot/m²) | 2,560,000 - 640,000 |
| Cabinet Resolution (W×H) | 960×540 - 480×270 |
| Cabinet Size (mm) | 600×337.5×34 |
Physical Specifications
| Cabinet Area | 0.2025 m² |
| Cabinet Weight | 4.1 kg |
| Flatness | ≤0.15 mm |
| Maintenance | Front Access |
| Protection Technology | COB |
| IP Rating | IP5X |
Optical Parameters
| Cabinet Material | Die-casting Aluminium |
| Brightness (nits) | 600 |
| Color Temperature (K) | 5000-10000 |
| Viewing Angle (H/V) | 165°/165° |
| Contrast Ratio | 12000:1 |
| Colour Depth (bits) | 22 |
Performance & Environmental
| Frame Rate (Hz) | 60 |
| Refresh Rate (Hz) | 3840-7680 |
| Power (W/m²) Max/Ave | ≤200-290 / ≤70-150 |
| Operating Temp (°C) | -10°C~45°C |
| Storage Temp (°C) | -20°C~55°C |
| Operating Humidity | 10%—85% (No condensation) |
Prismix Elite vs Traditional LED Displays
| Feature | Prismix Elite | Traditional LED |
|---|---|---|
| Technology | Chip-on-Board (COB) LED | Surface-Mounted Device (SMD) |
| Driver IC | Munorix INX Driver IC (All-in-One) | Separate Row & Column ICs |
| Power Efficiency | 35% Lower Power Consumption | Higher Energy Usage |
| Latency | Zero Delay (109ms Response) | Noticeable Lag |
| Refresh Rate | 7680Hz | 1920Hz – 3840Hz |
| Installation | HDMI Plug & Play, Simplified | Complex Network Cabling |
| Surface Temperature | ≤ 30°C (Cooler Surface) | Generates More Heat |
