Lumix
Outdoor LED screen family for robust day-to-day commercial use.
- 📺Outdoor LED commercial family
- 🔄Designed for recurring daily use
- 👁️Built for public-facing visibility
- 📢Suitable for large-format communication
- 🏗️Durable outdoor positioning
- 🚀Commercial deployment flexibility
Lightweight and Durable
Each cabinet weighs only 27kg with a slim 90mm profile, yet boasts reinforced construction for exceptional durability.
- ✓Only 27kg cabinet weight
- ✓Slim 90mm profile design
- ✓Reinforced construction
- ✓Exceptional durability
Advanced Engineering
Robust PCB Design
Featuring thicker, larger PCBs, our displays offer enhanced overload capacity and superior reliability.
Seamless Connectivity
Adjustable connectors ensure stable connections, while our innovative HUB design eliminates ribbon cables for a clean and efficient interior.
Superior Protection & Innovation
Superior Protection
IP66-rated with automotive-grade waterproof rings, withstands harsh weather conditions from -20°C to 60°C.
Innovative Splicing
Seamless splicing for perfect 3D effects; supports custom displays with right angles and rounded corners.
Smart Features
Superior wire management, concealed routing, and intelligent brightness control with automatic adjustments.
Technical Specifications
Display Specifications
| Specification | LUM40 | LUM50 | LUM66 | LUM80 | LUMA0 | LUMA6 |
|---|---|---|---|---|---|---|
| Model | Lumix | Lumix | Lumix | Lumix | Lumix | Lumix |
| Drive | Anode | Anode | Anode | Anode | Anode | Anode |
| Pixel Pitch (mm) | 4.0 | 5.0 | 6.67 | 8.0 | 10.0 | 16.0 |
| Cabinet Size (W*H*D) | 960x960x102 | 960x960x102 | 960x960x102 | 960x960x102 | 960x960x102 | 960x960x102 |
| Cabinet Resolution (W*H) | 240x240 | 192x192 | 144x144 | 120x120 | 96x96 | 60x60 |
| Weight (KG/Cabinet) | <22.5 | <22.5 | <22.5 | <22.5 | <22.5 | <22.5 |
| IP Rating | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
| Brightness (nit) | <5000 | <5500 | <6000 | <6500 | <10000 | <10000 |
| Viewing Angle (H/V,°) | 140/140 | 140/140 | 140/140 | 140/140 | 140/140 | 140/140 |
| Max Contrast Ratio | 7000:1 | 7000:1 | 7000:1 | 7000:1 | 7000:1 | 7000:1 |
| Refresh Rate (Hz) | 3840 | 3840 | 3840 | 3840 | 3840 | 3840 |
| Max Power Consumption (W/m²) | <650 | <630 | <600 | <580 | <500 | <500 |
| AVG Power Consumption (W/m²) | <215 | <208 | <198 | <192 | <150 | <150 |
Applications & Environments
Roadside Media
Highway and street advertising
Commercial Facades
Building exterior displays
Public Information
Transit and municipal displays
Brand Visibility
Corporate outdoor branding
Outdoor Signage
Commercial and retail signage
Event Displays
Outdoor event and festival screens
