Aurix
Multi-size indoor SMD cabinet family with nano optical coating and die-cast aluminum construction. Features 1.25mm pixel pitch with superior protection and front maintenance access.
- 🔬1.25mm pixel pitch precision
- 🛡️Nano optical coating protection
- ⚙️Die-cast aluminum construction
- 🔧Front maintenance access
- 📐Multiple cabinet size options
- 🎯Professional fixed-install positioning
Advanced Protection
Ultra Thin And Light
Aurix is the Munorix multi-size indoor SMD family for projects that need more dimensional flexibility than a single cabinet format can provide. Features nano optical coating for superior protection and longevity in demanding environments.
Waterproof Protection
Protects from water damage in high-humidity environments
Dust-Proof Design
Prevents debris from affecting display performance
Anti-Salt Spray
Resistance to corrosive salt spray for coastal areas
High-Temperature Resistant
Reliable performance in extreme temperature conditions
Robust Construction
Durable Cabinet Design
Durable cabinet design built to last with die-cast aluminum-magnesium alloy construction. Combines strength with lightweight properties for robust yet easy-to-handle cabinets that withstand physical stress.
Control Rooms
Advanced multi-size indoor platforms
Brand Walls
Custom proportions and cleaner composition
Corporate Lobbies
Professional fixed-install positioning
Broadcast Spaces
Refined commercial visual wall design
Custom Digital Signage
More adaptable screen planning
Easy Maintenance
Stunning Visuals
Front maintenance design enables quick and straightforward access to critical components. Easy access to modules, power units, and system cards without dismantling the entire display setup, minimizing downtime.
📋 Aurix Technical Datasheet
Display Specifications
| Model | KL12AA53 |
| LED Type | TOP 1010 |
| Pixel Pitch (mm) | 1.25 |
| Module Resolution (W×H) | 192×216 |
| Module Dimension (W×H,mm) | 240×270 |
| Cabinet Resolution (W×H,mm) | 384×432 |
Physical Dimensions
| Cabinet Size (W×H×D,mm) | 480×540×54 |
| Module Flatness (mm) | 0.1 |
| Pixel Density | 640,000 |
| Weight (KG/Cabinet) | 7 |
| Back Shell | Die-cast aluminum |
| Servicing | Front |
Protection Features
| Nano Optical Coating | Superior Protection |
| Waterproof | High-humidity environments |
| Dust-Proof | Consistent operation |
| Anti-Salt Spray | Coastal/industrial areas |
| Temperature Resistant | Extreme conditions |
| Anti-Radiation | EMI protection |
Construction & Maintenance
| Cabinet Material | Die-Cast Aluminum-Magnesium |
| Impact-Resistant | Physical stress protection |
| Corrosion-Resistant | Environmental durability |
| Silent Operation | Noise minimization |
| Front Maintenance | Easy component access |
| Installation Type | Indoor fixed positioning |
Indoor Applications & Environments
Control Rooms
Advanced monitoring & operations
Brand Walls
Corporate identity displays
Corporate Lobbies
Professional reception areas
Broadcast Spaces
Studio & production environments
Digital Signage
Custom indoor installations
Meeting Rooms
Presentation & collaboration
