Mira
Revolutionary indoor LED display featuring cutting-edge QCOB Film Technology and premium die-cast aluminum construction. Delivers exceptional 8K+ resolution with advanced color reproduction and versatile installation options.
- 🎯Ultra-high-definition 8K+ resolution support
- ⚡≥3,840Hz refresh rate for flicker-free viewing
- 🔧Front & rear maintenance with module access
- 🌡️Fanless operation with natural heat dissipation
- 💎14-18 bit color depth processing
- 🔒Waterproof, dustproof & salt spray resistant
Advanced Technology
QCOB Film Technology
Revolutionary Quantum Chip-on-Board Film Technology delivers exceptional durability, high-temperature resistance, and anti-collision protection with wide viewing angles.
Durability
Waterproof, dustproof, and salt spray-resistant for challenging environments
Temperature Resistance
Reliable operation in high-temperature conditions
Wide Color Gamut
Expansive color range for vibrant, accurate visuals
Premium Construction
Die-Cast Aluminum Cabinet
High-quality die-cast aluminum construction ensures precision engineering, pressure resistance, and natural heat dissipation for fanless operation.
Performance & Efficiency
Exceptional Specifications
Top-tier performance with ultra-high refresh rates, superior color depth, and up to 45% energy savings through Common Cathode Technology.
📋 Technical Datasheet
Display Technology
| Technology Type | QCOB Film Technology |
| Resolution Support | Beyond 8K Ultra-HD |
| Aspect Ratios | 4:3 to 16:9 flexible |
| Pixel Pitch | P1.25 - P2.5 available |
| LED Type | SMD Black LEDs |
| Module Size | 320×160mm |
Performance
| Refresh Rate | ≥3,840Hz |
| Contrast Ratio | ≥7,000:1 |
| Color Depth | 14-18 bit processing |
| Viewing Angle | ≥160° (H/V) |
| Response Time | Nanosecond precision |
| Brightness | 1,200 cd/m² |
Physical & Construction
| Cabinet Material | Die-cast aluminum |
| Cabinet Size | 640×480×68mm |
| Weight | 8.5kg per cabinet |
| Protection Rating | Waterproof & dustproof |
| Heat Dissipation | Natural fanless cooling |
| Flatness Adjustment | ±125μm Z-axis precision |
Power & Environmental
| Power Supply | DC2.8V / DC3.8V dual-channel |
| Energy Savings | Up to 45% vs traditional |
| Temperature Rise | 30% reduction |
| Operating Temperature | -20°C to +60°C |
| Humidity Range | 10% to 90% RH |
| Lifespan | 100,000+ hours |
Installation & Maintenance Options
Ground Stacking
Temporary setups and events
Wall Mounting
Permanent installations
Arc Mounting
Curved immersive displays
Front/Rear Access
Easy module maintenance
Hot-Swappable
Power & data connections
Tool-Free Service
Quick component replacement
